Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: CNRUIHUA
  • Model Number: K3808
  • Usage: Position Sensor
  • Theory: Inductance Sensor
  • Output: Digital Sensor
  • hollow shaft encoder: AHC3808

Packaging & Delivery

Packaging Details: hollow shaft rotary encoder carton
Delivery Detail: hollow shaft rotary encoder in 5 days after your payment
hollow shaft rotary encoder
certificate: CE

Hollow shaft encoder Applications:
Power motors and three phase current motors with frequency transformation,
system construction.
Hollow Shaft diameter Φ8mm, housing diameter Φ 38mm,SSI protocol



2000 Pairs Sells per Month

5 pairs MOQ

48-72 hours delivery after received money



ELECTRICAL SPEC







output circuit

open collector NPN output

voltage output

push pull output

line driver output

supply voltage

5-24

5-24

5± 0.25  5-24

5± 0.25  5-24

current consumption

≤ 80mA

≤ 80mA

≤ 80mA

≤ 150mA

load current

40mA

40mA

40mA

60mA

single high level

min Vcc*70%

min Vcc-2.5V

min Vcc-1.5V

min 3.4V

single low level

Max 0.4V

Max 0.4V

Max0.8V

Max 0.4V

rising time Tr

Max 1us

Max 1us

Max 1us

Max 200ns

declining time Tr

Max 1us

Max 1us

Max 1us

Max 200ns

response frequency

300kHz

300kHz

300kHz

300kHz

MECHANICAL SPEC







number of pulses

starting torque without sealing

Max load permitted on shaft

shock resistance

vibration proof

2500

≤ 0.05Nm

radial 50N, Axial 20N

50G /11ms

10G 10-2000Hz

rotational inertia

Working temperature

Storage temperature

protect class

Weight

4x10 -8 kgm 2

  - 30 ~ 85 C

  - 35 ~ 95  C

IP65

100g



hollow shaft encoder TECHNICAL SPECIFICATION
ELECTRICAL SPECIFICATIONS
Output wave
Square wave
Current consumption
≤150mA
Response Frequency
0-50KHz
Supply voltage
DC+5V±5%
Signal level
VH≥85%Vcc,VL≤0.3V
Output circuit
COpen collector NPNEVoltage
MECHANICAL SPECIFICATIONS
Speed without sealing
1000rpm
Rotor moment of inertia
5×106kgm2
Starting torque without sealing
2.5×103Nm(+25)
&ltd>
Maximum load permitted on shafton shaft
Radial 20N,Axial 10N
Vibration proof
980m/s2,6ms,2 times each on XYZ
Shock resistance
50m/s2,10-200Hz,XYZ2h
Working life
MTBF≥10000h+250,2000rpm
Weight
0.2KG with 1 meter ccable
ENVIRONMENTAL SPECIFICATIONS
Working life
30-85% (No condensation)
Storage temperature
300C850C
Working temperature
-2585
protect class
waterproof,dustproof IP54
SPECIFICATION PARAMETER
Code
Bit
Point for round
Angle distinguish
Output code
Carry direction
Output circuit
AHC3808001G0007
7
128
360°/127
Gray code/ nature binary system /two code
shaft end
according to the clock wise(CW)
Parallel output
AHC3808001G0008
8
256
360°/128
Parallel or serial output
AHC3808001G0009
9
512
360°/129
Serial output
AHC3808001G0010
10
1024
360°/1210
Serial output
AHC3808001G0011
11
2048
360°/1211
Serial output
AHC3808001G0012
12
4096
360°/1212
Serial output
AHC3808001G0013
13
8192
360°/1213
Serial output
Terminal Assignment


Code specification:

Series:AHC3808,output digit:13 bit, nature binary system two code,power supply:DC5V ,Line driver output

Recoder : AHC3808001G-0013BZ-5L

...
